      Below are the New product information .

RGB LED PANEL PRODUCT SPECIFICATION

一、【Features】

•Attractive and durable: aluminum alloy and ultra-thin design, concise style;

• Light source soft and uniformity, no light spot: lateral shoot light source will change the point light to area light and science technology make more soft light, create the most suitable light environment.

• Compact structure, good heat dissipation performance: using high quality aluminum alloy, good heat dissipation design reduces the LED heat and lumens depreciation, make lamps use longer.

• Convenient installation: the entire product only 12.5 mm thickness, weight light, convenient installation.

• High safety: high efficiency LED constant current power supply, start quick, lower power and less heat.

• Green environmental protection:no harmful material,no ultraviolet light, using the recycling acrylic and aluminum alloy material.

• Life long, the seismic performance is good: long life can reach over than 30000 hours, optical acrylic and high quality aluminum, non-friable.

• Maintainable: easy to maintain, no need to change all panel when just one or two led chips damaged.

二、【Technology parameters】
• light source: 3528 LED chips package

• Power types: external type constant current power supply

• Input voltage: 90-254 VAC / 50-60hz, output: three road constant current, every road 320 m A ± 10 mA, the output voltage 36-42 VDC, realize the colorful gradient etc.

• Power factor: ≥0.85

• Luminous flux

Item	ESD-MB-3030-C4-GNF09-A1
Power	9W
Lamp chip	144 SMT RGB 3528
Light source	Epistar
Red light wavelengths（nm）	630
Green light wavelengths（nm）	530
Blue wavelengths(nm)	470

• Color temperature: RGB

• CRI: /

• Beam angle: 120 °

• Material: Aluminum+LGP+PMMA

• Life expectancy: > 30000 hours.

• Working environment: indoor, temperature range-25 ℃ ~ 45 ℃, humidity range from 10% to 90%.

• Certification: CE, RoHS

三.

Model	ESD-MB-3030-C4-GNP09-A1
Light source	Domestic chip	Epistar chip
1 M is in (a) intensity of illumination (Lx)	64	89
2 M place (b) intensity of illumination (Lx)	21	26
3 M place (c) intensity of illumination (Lx)	10	17

四、【 Application 】：

      The office, market, hotel, exhibition hall, entertainment applications and other places

五、【The user installation and instructions】：

Electrical connection mode:

Direct exchange of the input power network (L) and zero line (N) respectively after receiving lamps the control of the power supply logo 'RGB L' and 'N' corresponding terminals. If there is safely (PG), please marks “PG” from the terminals can normal use (below).



       Instructions:

1. Before install, be confirm that top ceiling can bear the weight of the lamps, more safety way is that can adopt wire rope or ceiling installation embedded in way.

2. Be confirm that whether power grid accord with the work lamps supply voltage specification, above or below the is not allowed.

3. Install the connection should be completely cut off power supply in case short circuit or get an electric shock risk.

4. Don't disassemble lamps and lanterns by yourself, in case safety protection reduce caused fault.

5. Lamps can only used indoor, outdoor and wet work situation is not permitted, installation area should be far away from heat lamps, vibration sources.

6. Lamps external wire protect: do not force pulling, if wire damaged, should stop using the lamps and lanterns.

7. It is strictly prohibited to strong corrosive chemicals contact with any part of the lamps.

六、【Packing and marking】： Modle ESD-MB-3030-C4-GNF09-A1 Size Material pcs/box outer box 400x380x78mm A=B 2 LED SPotlight PRODUCT SPECIFICATION Module：    ESD-SD-E39-00-GQP120-A1 ESD-SD-E39-00-GQW120-A1 ESD-SD-E39-00-GQN120-A1 ESD-SD-E39-00-GQC120-A1 一、【Features】 • Energy saving, energy saving lamps than ordinary power saving 50%-70%. • Environmental protection; Lead-free, mercury and other environmental harmful material, and also have no ultraviolet ray, infrared, harmful to human body health of radiation. • Beautiful shape: high thermal conductivity fins aluminum shells the oxidation process, color and luster is light, spherical mask with pleasing appearance and shape. • Long service life: life is the same type of traditional lights 5 to 8 times, save maintenance cost. • The radiation capability good: high thermal conductivity aluminum shell fins good heat dissipation characteristics plus excellent thermal design will heat are effective, and extend the life of LED. • Lamp holder type can change: lamp holder type can choose E39, E40 to adapt to different lamp holder, increased the range. • Convenient installation: just like ordinary incandescent lamp bulb installed as twist in the corresponding lamp holder can. • High safety: built-in isolation type power supply, effectively prevent to get an electric shock risk leakage. • Easy maintenance: light source or the power supply damage, only need to change the corresponding element can complete maintenance continue to work properly. • Protect vision: the glare structure design, reduce illume process not comfort, no flash, and effectively protect eyes. • No electromagnetic interference: be other appliances and electromagnetic interference. 二、【Technology parameters】 • Light source: 1 W encapsulation LED • LED quantity：120PCS • Interface type: E39 (E40) can be chosen • Power types: built-in constant-current power supply • Input voltage：AC90V-250V/50-60HZ • Power：120W • Power factor：≥0.85 • Luminous flux Light source categories LED lamp bead (PCS) Flux (lm) The luminous efficiency (lm/w） CREE chip 120  10020 101.8 Wafer chip 120  9340  93.4 Domestic chip 120  7460 74.6 • Color temperature: W-warm white (2700-3700 K), N-natural white (3700-5500 K): P-is white (5500-6500 K), C-cold white (7000-9000 K) can be chosen • CRI: 70 frequencies • Beam Angle: 120 ° • working temperature:-25 ℃ ~ 45 ℃ • Protection rating: IP54 • Material: 1050 fins aluminum shell + PMMA mask. • Life expectancy: > 30000 hours. • working environment: indoor use, temperature range-25 ℃ ~ 45 ℃, humidity range from 10% to 90%. • Weight: product = 3772 g, product + packing box = 4265 g. • Certification: CE, RoHS 三、【Application】：    Public places (market, hotel, school, station, warehouse, parking places such as the main illumination) Installation: hold light bulb metal outer shell part directly mounted on the corresponding bulb twist E39 or E40 lamp holder can. Can't hold mask can be part of the pack, otherwise damaged lamps and lanterns Instructions: 1. Installation and replace lamps need to completely shut off the power again after operation. 2. before installing needs confirmation whether the lamp installation and light bulb lamp holder supporting. 3. Avoid installation in high temperature, high humidity and close to the heat source place and heat steam, the place of corrosive gas, lest affect life span. 4. Install lamp holder type: E39, E40 四、【Packing and marking】： Packaging methods: outside the box Packing method: Pearl cotton + outside the box Outside the box 400 * 400 * 400 (mm) 1 PCS/pack material A = B
