900mm Mini Bracket T5 LED Tube
Eastar LED Tube is one of the kind. As a professional LED tube maker, the product family includes T8/T10 and T5 Tube series. T8 LED Tube has standard, dimming and explosion-proof series for different applications. T5 Tube has standard and mini bracket series.
By using SMD LED Tube 3014/3528 from Cree/Epistar, high heat transmission PCB board, constant current driver, two years warranty can be met easily.
Different lengths, wide voltage and various color temperature are optional. Eastar LED Tube is easy to installation and will bring the LED lighting into your place and help you save a lot on your bill.
Model: ESD-ZRG-T5-0900-GSP11-E1 (transparent PC cover)
ESD-ZRG-T5-0900-GTP11-E1 (stripe PC cover)
ESD-ZRG-T5-0900-GDP11-E1 (frosted PC cover)
Features:
1 No need for starter and EM ballast, direct live voltage input
2 Toxic-free materials-does not contain glass, lead or mercury
3 Vibration proof and retains stable performance in tough environment
4 Can be directly placed in conventional T4 or T5 fluorescent brackets, remove ballast and starter before replacement.
2 Toxic-free materials-does not contain glass, lead or mercury
3 Vibration proof and retains stable performance in tough environment
4 Can be directly placed in conventional T4 or T5 fluorescent brackets, remove ballast and starter before replacement.
Applications:
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
| Specifications | |
| Lighting name | 900mm Mini Bracket T5 LED Tube |
| Total power consumption | 14W |
| LED consumption | 11W |
| Input voltage | AC85-264V, 50/60Hz |
| Driver output | 35-42VDC/380-400mA |
| Tube input | 40VDC/380-400mA |
| Power supply | Internal constant current |
| Lighting source | 180pcs low power 3528 LED |
| Dimension | 28mm*25mm*871mm |
| Material | Aluminum+PC cover (transparent, striped, frosted) |
| Luminous flux | 1100lm±10% |
| Luminous efficiency | 75–85lm/W |
| Color temperature | 2700-4500K, 4500-6500K, 6500-9000K |
| Viewing angle | 120 degrees |
| CRI | Ra>70 |
| Working temperature | -20~40°C |
| Environment humidity | <90% |
| Working environment | indoor use (applicable for dry environment) |
| Life-span | 50,000 hours |
| Net Weight | 300g |
| Certification | CE, RoHS and FCC |
| Warranty | 2 years |
Eastar LED Tube is one of the kind. As a professional LED tube maker, the product family includes T8/T10 and T5 Tube series. T8 LED Tube has standard, dimming and explosion-proof series for different applications. T5 Tube has standard and mini bracket series.
By using SMD LED Tube 3014/3528 from Cree/Epistar, high heat transmission PCB board, constant current driver, two years warranty can be met easily.
Different lengths, wide voltage and various color temperature are optional. Eastar LED Tube is easy to installation and will bring the LED lighting into your place and help you save a lot on your bill.
Model: ESD-ZRG-T5-0900-GSP11-E1 (transparent PC cover)
ESD-ZRG-T5-0900-GTP11-E1 (stripe PC cover)
ESD-ZRG-T5-0900-GDP11-E1 (frosted PC cover)
Features:
1 No need for starter and EM ballast, direct live voltage input
2 Toxic-free materials-does not contain glass, lead or mercury
3 Vibration proof and retains stable performance in tough environment
4 Can be directly placed in conventional T4 or T5 fluorescent brackets, remove ballast and starter before replacement.
2 Toxic-free materials-does not contain glass, lead or mercury
3 Vibration proof and retains stable performance in tough environment
4 Can be directly placed in conventional T4 or T5 fluorescent brackets, remove ballast and starter before replacement.
Applications:
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
| Specifications | |
| Lighting name | 900mm Mini Bracket T5 LED Tube |
| Total power consumption | 14W |
| LED consumption | 11W |
| Input voltage | AC85-264V, 50/60Hz |
| Driver output | 35-42VDC/380-400mA |
| Tube input | 40VDC/380-400mA |
| Power supply | Internal constant current |
| Lighting source | 180pcs low power 3528 LED |
| Dimension | 28mm*25mm*871mm |
| Material | Aluminum+PC cover (transparent, striped, frosted) |
| Luminous flux | 1100lm±10% |
| Luminous efficiency | 75–85lm/W |
| Color temperature | 2700-4500K, 4500-6500K, 6500-9000K |
| Viewing angle | 120 degrees |
| CRI | Ra>70 |
| Working temperature | -20~40°C |
| Environment humidity | <90% |
| Working environment | indoor use (applicable for dry environment) |
| Life-span | 50,000 hours |
| Net Weight | 300g |
| Certification | CE, RoHS and FCC |
| Warranty | 2 years |
